Cummins Engine

Description

● We have STAMFORD, Marathon, Leroy-Somer and other famous alternators for your choice
● Cummins series have good quality, low fuel consumption, low noise, high output power and reliable performance.
● Its reliable stability, economy, power, durability and environmental safety by domestic and customers welcome, the global three bags of Lien.
● International Warranty Service, Spare parts are easy to get from worldwide market with much cheaper price.

Cummins Inc., a global power leader, is a corporation of complementary business units that design, manufacture, distribute and serve engines and related technologies, including fuel systems, controls, air handling, filtration, emission solutions and electrical power generation systems. Headquartered in Columbus, Indiana (USA), Cummins serves customers in approximately 190 countries and territories through a network of more than 500 company-owned and independent distributor locations and approximately 5,200 dealer locations.

Chongqing Cummins Engine Co., Ltd. (CCEC) is the first production base invested by Cummins Inc. with a large power range from 250kva to 1500kva.

–

50Hz

Genset model	Output power		Engine model	Bore*Stroke (mm)	CYL	Displacement （L）	Lube （L）	Fuel consumption g/kw.h	Dimension (mm)	Weight (Kg)
Genset model	KW	KVA	Engine model	Bore*Stroke (mm)	CYL	Displacement （L）	Lube （L）	Fuel consumption g/kw.h	Dimension (mm)	Weight (Kg)
WP-C20GF	20	25	4B3.9-G2	102*120	4	3.9	11	208	16507201200	700
WP-C24GF	24	30	4B3.9-G2	102*120	4	3.9	11	208	16507201200	700
WP-C24GF	24	30	4B3.9-G1	102*120	4	3.9	11	208	16507201200	710
WP-C30GF	30	37.5	4BT3.9-G2	102*120	4	3.9	11	208	17007201200	800
WP-C30GF	30	37.5	4BT3.9-G1	102*120	4	3.9	11	208	17007501200	810
WP-C40GF	40	50	4BTA3.9-G2	102*120	4	3.9	11	210	18007501200	920
WP-C50GF	50	62.5	4BTA3.9-G2	102*120	4	3.9	11	210	18007501200	950
WP-C64GF	64	80	4BTA3.9-G11	102*120	4	3.9	11	210	18508001300	1000
WP-C80GF	80	100	6BT5.9-G2	102*120	6	5.9	16	210	22508001300	1250
WP-C80GF	80	100	6BT5.9-G1	102*120	6	5.9	16	210	22508001300	1260
WP-C100GF	100	125	6BTA5.9-G2	102*120	6	5.9	20	207	22508001300	1300
WP-C120GF	120	150	6BTAA5.9-G2	102*120	6	5.9	24	207	22508301300	1350
WP-C132GF	132	165	6BTAA5.9-G12	102*120	6	5.9	24	207	23008301300	1380
WP-C150GF	150	187.5	6CTA8.3-G2	114*135	6	8.3	24	207	23509701500	1600
WP-C150GF	150	187.5	6CTA8.3-G1	114*135	6	8.3	24	207	23509701500	1600
WP-C180GF	180	225	6CTAA8.3-G2	114*135	6	8.3	24	207	24009701500	1700
WP-C200GF	200	250	6LTAA8.9-G2	114*145	6	8.9	28	207	260010701500	2000
WP-C220GF	220	275	6LTAA8.9-G3	114*145	6	8.9	28	203	260010701500	2050
WP-C320GF	320	400	6ZTAA13-G3	130*163	6	13	28	202	290012001750	3000
WP-C400GF	400	500	6ZTAA13-G4	130*163	6	13	28	202	290012001750	3060
WP-C400GF	400	500	QSZ13-G2	130*163	6	13	28	201	315013501800	3200
WP-C450GF	450	562.5	QSZ13-G3	130*163	6	13	28	201	315013501800	3250
CCEC series
WP-C200GF	200	250	MTA11-G2	125*147	6	11	38	206	300010501700	2200
WP-C200GF	200	250	NT855-GA	140*152	6	14	38	206	300010501750	2600
WP-C250GF	250	312.5	NTA855-G1A	140*152	6	14	38	207	310010501750	2880
WP-C280GF	280	350	MTAA11-G3	125*147	6	11	38	210	310010501750	2900
WP-C280GF	280	350	NTA855-G1B	140*152	6	14	38	206	310010501750	2950
WP-C300GF	300	375	NTA855-G2A	140*152	6	14	38	206	320010501750	3000
WP-C320GF	320	400	NTA855-G4	140*152	6	14	38	205	320011001800	3100
WP-C350GF	350	437.5	NTAA855-G7A	140*152	6	14	38	205	330012501850	3200
WP-C400GF	400	500	KTA19-G3A	159*159	6	18.9	50	206	330014001970	3700
WP-C450GF	450	562.5	KTA19-G3A	159*159	6	18.9	50	206	330014001970	3750
WP-C480GF	480	600	KTA19-G8	159*159	6	18.9	50	206	350015002000	4200
WP-C500GF	500	625	KTA19-G8	159*159	6	18.9	50	206	350015002000	4260
WP-C530GF	530	662.5	KTAA19-G6A	159*159	6	19	50	206	360015002000	4800
WP-C600GF	600	750	KT38-GA	159*159	12	38	100	206	430017002350	7000
WP-C640GF	640	800	KTA38-G2	159*159	12	37.8	100	206	430017002400	7500
WP-C700GF	700	875	KTA38-G2B	159*159	12	37.8	100	206	440017502450	8000
WP-C800GF	800	1000	KTA38-G2A	159*159	12	37.8	100	206	450017502450	8200
WP-C824GF	824	1030	KTA38-G5	159*159	12	37.8	120	208	450018002350	8800
WP-C900GF	900	1125	KTA38-G9	159*159	12	37.8	135	208	450018002350	9200
WP-C1000GF	1000	1250	KTA38-G9	159*159	12	37.8	135	208	450018002350	9200
WP-C1000GF	1000	1250	KTA50-G3	159*159	16	50.3	177	205	530020802500	9900
WP-C1100GF	1100	1375	KTA50-G3	159*159	16	50.3	177	205	530020802500	10000
WP-C1200GF	1200	1500	KTA50-G8	159*159	16	50.3	204	205	570022802500	10500
WP-C1200GF	1200	1500	KTA50-GS8	159*159	16	50.3	204	205	570023002500	11000

Model with “E” are standby power gensets;
China 0# light diesel or higher are recommended for sutech gensets with oil water separator to ensure purity fuel.
Suggest to adopting API CF or higher oil, temperature/viscosity of 15W-40
This parameter table is only for reference and no notice any more if have change.

–

60Hz

Genset model	Output power		Engine model	Bore*Stroke (mm)	CYL	Displacement （L）	Lube （L）	Fuel consumption g/kw.h	Dimension (mm)
Genset model	KW	KVA	Engine model	Bore*Stroke (mm)	CYL	Displacement （L）	Lube （L）	Fuel consumption g/kw.h	Dimension (mm)
DCEC series
WP-C40GF	40	32	4B3.9-G2	102*120	4/L	3.9	11	21.4	16008301388
WP-C50GF	50	40	4BT3.9-G2	102*120	4/L	3.9	11	214	16508301388
WP-C75GF	75	60	4BTA3.9-G2	102*120	4/L	3.9	11	216	16878301388
WP-C100GF	100	80	4BTA3.9-G11	102*120	4/L	3.9	11	216	17208301388
WP-C100GF	125	100	6BT5.9-G2	102*120	6/L	5.9	16	214	22008501440
WP-C150GF	150	120	6BTA5.9-G2	102*120	6/L	5.9	16	214	22008501440
WP-C165GF	165	132	6BTAA5.9-G2	102*120	6/L	5.9	16	211	22128501440
WP-C185GF	185	148	6BTAA5.9-G12	102*120	6/L	5.9	16	211	22128501440
WP-C210GF	210	168	6CTA8.3-G2	102*120	6/L	5.9	16	208	23909501561
WP-C240GF	240	192	6CTAA8.3-G2	114*135	6/L	8.3	24	210	248010201605
WP-C275GF	275	220	6LTAA8.9-G2	114*145	6/L	8.9	28	205	248010201596
WP-C315GF	315	252	6LTAA8.9-G3	114*145	6/L	8.9	28	205	248010201596
WP-C500GF	500	400	6ZTAA13-G4	114*145	6/L	13	28	205	320013601800
WP-C560GF	560	448	QSZ13-G3	130*163	6/L	13	28	201	330013601800
CCEC series
WP-C350GF	350	280	NTA855-G1	140*152	6/L	14	39	197	286011001863
WP-C375GF	375	300	NTA855-G1B	140*152	6/L	14	39	200	286011001863
WP-C440GF	440	352	NTA855-G3	140*152	6/L	14	37	194	314211001863
WP-C560GF	560	448	KTA19-G3A	159*159	6/L	19	50	204	326513552030
WP-C690GF	690	552	KTA19-G5	159*159	6/L	19	50	204	351015002055
WP-C750GF	750	600	KTAA19-G6A	159*159	6/L	19	50	204	354015002055
WP-C800GF	800	640	KT38-G	159*159	12/V	37.8	135	208	430020102475
WP-C940GF	940	752	KT38-G1	159*159	12/V	37.8	135	208	435020102475
WP-C1000GF	1000	800	KAT38-G2	159*159	12/V	37.8	135	200	440020102475
WP-C1060GF	1060	848	KTA38-G2B	159*159	12/V	37.8	135	200	445020102475
WP-C1125GF	1125	900	KTA38-G2A	159*159	12/V	37.8	135	200	460020102475
WP-C1250GF	1250	1000	KTA38-G4	159*159	12/V	37.8	135	202	456020102475
WP-C1375GF	1375	1100	KTA38-G9	159*159	12/V	37.8	135	202	458020102475
WP-C1500GF	1500	1200	KTA50-G3	159*159	16/V	50.8	204	201	507320102510
WP-C1875GF	1875	1500	KTA50-G9	159*159	16/V	50.8	204	201	525820102620
